Dixell XR02CX Controller Manual and Parameters for Unifrost Cabinets

Use this page when a Unifrost cabinet is running a Dixell XR02CX controller and you need the correct PDF before changing a set-point or parameter. The XR02CX appears across several Unifrost fridge, prep, display, and compact cabinet families, so checking the controller label is often faster than searching by model name alone.

Download XR02CX PDF
Manuals library
Troubleshooting

Primary jobMatch controller to PDF

Use beforeChanging set-points

Support typeShared across Unifrost cabinets

At a glance before you change anything

Check the controller label against the PDF before changing settings. If the problem is broader than the controller, use the model-specific or troubleshooting guidance.

Step 1

Match the fascia label

Use the exact controller label and button layout before trusting a nearby model number or old service note.

Step 2

Capture the current display

Note the set-point, alarm code, and display state before you power-cycle the cabinet or edit values.

Step 3

Rule out non-controller faults

Airflow, loading, condenser cleanliness, and door sealing can all look like parameter problems.

Download the correct controller PDF first

Use the matching controller PDF before you change a set-point, parameter, or alarm-related value.

PDF download

Dixell XR02CX controller manual

Original PDF manual. 274.0 KB.

Manuals and downloads library

Use the wider manuals page if you also need a cabinet manual rather than just the controller PDF.

Common Unifrost model groups using this controller

The same controller often appears across multiple cabinet families. Match the controller label first, then use the cabinet model to find the relevant guidance.

CR1360FT / CR1360G / CR2230G upright and counter fridge models.
DCF1300 / DCF1600 and HGP90 / HGP120 models that use the XR02CX controller.
HVF11B / HVF22B, HVR21B / HVR22B / HVR33B, R1000SVN, R200SVN, R200SN and SA136G models that use this controller.

Use this controller page when you need to

Use this page alongside the exact controller PDF for your equipment.

Confirm the right controller PDF before changing the chilled set-point or any hidden parameters.
Check the controller label and button layout when the cabinet model is unclear or partially worn on the rating plate.
Capture the exact alarm or display state before power-cycling the unit.
Decide whether the issue is controller-led or more likely to be airflow, loading, condenser, or door-related.

Always use the exact controller PDF for button sequences, parameter codes, and wiring or alarm details. The guidance on this page does not replace the manufacturer document.
